| Place of Origin: | China |
|---|---|
| Brand Name: | Powerplus |
| Certification: | ISO 9001 |
| Minimum Order Quantity: | 1 SET |
| Packaging Details: | Plyfilm or plywood suitable for sea shipping |
| Delivery Time: | 45-60 DAYS |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 SETS PER MONTH |
| Working Power: | 5.5-11kW / 7.5-15hp | FAD (Free Air Delivery): | 0.72-1.76m³/min；25-62cfm |
|---|---|---|---|
| Working Pressure: | 7.5-13 Bar / 109-189 PSI | Certificate: | CE, ISO9001 |
| Temperature: | -270℃/518℉ ~ 400℃/752℉ | ||
| Highlight: | 15hp belt driven air compressor,belt driven air compressor 5.5kw,11kw belt drive air compressor |
||
| Model | Maximum working pressure | Capacity FAD* | Installed motor power | Driving mode & Cooling method | Dimensions(mm) | Weight(kg) | Noise level | Airoutlet pipe diameter | |||||||
| 50Hz | 60Hz | ||||||||||||||
| bar(e) | psig | m3/min | cfm | m3/min | cfm | kw | hp | Belt Driven Air Cooling | L | W | H | kg | dB(A) | ||
| DA-5 | 7.5 | 109 | 0.85 | 30 | 0.87 | 31 | 5.5 | 7.5 | 900 | 660 | 960 | 180 | 62 | G3/4 | |
| 8.5 | 123 | 0.81 | 29 | 0.84 | 30 | 5.5 | 7.5 | 900 | 660 | 960 | 180 | 62 | G3/4 | ||
| DA-7 | 7.5 | 109 | 1.04 | 37 | 1.02 | 36 | 7.5 | 10 | 900 | 660 | 960 | 200 | 62 | G3/4 | |
| 8.5 | 123 | 0.98 | 34 | 1 | 35 | 7.5 | 10 | 900 | 660 | 960 | 200 | 62 | G3/4 | ||
| 10.5 | 152 | 0.89 | 32 | 0.89 | 32 | 7.5 | 10 | 900 | 660 | 960 | 200 | 62 | G3/4 | ||
| 13 | 189 | 0.72 | 25 | 0.74 | 26 | 7.5 | 10 | 900 | 660 | 960 | 200 | 62 | G3/4 | ||
| DA-11 | 7.5 | 109 | 1.76 | 62 | 1.76 | 62 | 11 | 15 | 900 | 660 | 960 | 255 | 62 | G3/4 | |
| 8.5 | 123 | 1.73 | 61 | 1.7 | 60 | 11 | 15 | 900 | 660 | 960 | 255 | 62 | G3/4 | ||
| 10.5 | 152 | 1.37 | 48 | 1.37 | 48 | 11 | 15 | 900 | 660 | 960 | 255 | 62 | G3/4 | ||
| 13 | 189 | 1.12 | 40 | 1.12 | 40 | 11 | 15 | 900 | 660 | 960 | 255 | 62 | G3/4 | ||
