| Place of Origin: | China |
|---|---|
| Brand Name: | Powerplus |
| Certification: | ISO 9001 |
| Minimum Order Quantity: | 1 SET |
| Packaging Details: | Plyfilm or plywood suitable for sea shipping |
| Delivery Time: | 45-60 DAYS |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 SETS PER MONTH |
| Working Pressure: | 3 Bar / 43.5 PSI | FAD (Free Air Delivery): | 264-2447cfm; 7.46-69.3m³/min |
|---|---|---|---|
| Working Power: | 55-250 KW / 75-350 Hp | ||
| Highlight: | 43.5psi low pressure screw air compressor,low pressure screw air compressor 55 kw,43.5psi centrifugal air compressor |
||
| Model | Maxinmum working pressure | Capacity(FAD)* | Installed motor | driving mode & Cooling method | Dimensions(mm) | Weight | Noise level** | Air outlet pipe diameter | |||||||||||
| 50 HZ | 60 HZ | power | |||||||||||||||||
| bar(e) | psi | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | kw | hp | L | W | H | kg | dB(A) | |||
| m³/min | cfm | m³/min | cfm | ||||||||||||||||
| VAL-55-3 | 3 | 43.5 | 8.39 | 16.78 | 296 | 592 | 7.46 | 14.92 | 264 | 527 | 55 | 75 | Direct Driven Air Cooling /W-Water Cooling |
2950 | 1800 | 2300 | 1800 | 70 | DN50 |
| VAL-75-3 | 11.55 | 23.1 | 408 | 816 | 12.22 | 24.44 | 432 | 863 | 75 | 100 | 2950 | 1800 | 2300 | 1900 | 70 | DN80 | |||
| VAL-90-3 | 12.78 | 25.57 | 452 | 903 | 13.85 | 27.71 | 489 | 978 | 90 | 120 | 2950 | 1800 | 2300 | 2500 | 74 | DN80 | |||
| VAL-110-3 | 16 | 31.99 | 565 | 1130 | 14.12 | 28.25 | 499 | 997 | 110 | 150 | 3700 | 2300 | 2450 | 3700 | 74 | DN80 | |||
| VAL-132-3 | 17.89 | 35.77 | 632 | 1263 | 15.36 | 30.71 | 542 | 1084 | 132 | 175 | 3700 | 2300 | 2450 | 4000 | 74 | DN80 | |||
| VAL-160-3 | 19.51 | 39.02 | 689 | 1378 | 17.55 | 35.09 | 620 | 1239 | 160 | 215 | 3700 | 2300 | 2450 | 4500 | 77 | DN80 | |||
| VAL-185(W)-3 | 21.76 | 43.51 | 768 | 1536 | 22.58 | 45.15 | 797 | 1594 | 185 | 250 | 3700 | 2300 | 2450 | 5200 | 77 | DN100 | |||
| VAL-250(W)-3 | 31.5 | 63 | 1113 | 2225 | 34.65 | 69.3 | 1224 | 2447 | 250 | 350 | 4300 | 2400 | 2350 | 6600 | 82 | DN100 | |||
